Part 2 introduced the database layer of nsw-legal-research-assistant in passing — two tables, Document and Chunk, enough to get retrieval working end to end. The app has grown considerably since then: nine tables now, a Brief Builder workflow, chat history, wiki pages, trust tiers. The database layer itself, though, has stayed remarkably stable in shape — the same Postgres instance, the same pgvector extension, the same cosine-distance query at the centre of everything. This post is the deep dive that earlier one was not: the full schema as it exists today, why Postgres was the right call for a vector store here (the reasoning is written up as ADR-0002 in the sibling repo's llmwiki, not just something I decided informally), a step-by-step Docker build a system administrator could follow from nothing but a base Postgres image, and — because I keep circling back to whether I would build this app the same way twice — how the same database layer could be scaffolded by a Claude Code user through GitHub's Spec Kit instead of by hand.

A toy example: cosine distance with three numbers, by hand

Before 768-dimension real vectors and a 20,000-row real table, here is the entire mechanism this post is about, at a size a calculator could check. Cosine distance measures the angle between two vectors, ignoring their length — two vectors pointing the same direction score as identical even if one is twice as long as the other, which is exactly the property that lets it compare a short question against a long paragraph of judgment text fairly. Three toy "documents," each reduced to a 3-number vector, and one toy "question":

Run against a real, throwaway table on the same live Postgres this series has traced throughout (not hand-calculated, not simulated):

"About dogs" scores a distance of exactly 0 against a query pointing in the identical direction — a perfect match. "About cats" is nearly identical (0.0061) because its vector points almost the same way, just tilted slightly by that 0.1 in the second position. "About taxes" scores the maximum distance, 1, because its vector points in a completely unrelated direction (no overlap with the first two numbers at all). This is the entire idea chunks.embedding <=> query_vector scales up to 768 dimensions and 20,000 real rows below — nothing conceptually different happens at real scale, there are just many more numbers per vector and many more rows to rank.

Why Postgres, not a dedicated vector database

The obvious alternative to pgvector is a purpose-built vector database — Pinecone, Weaviate, Qdrant, and others exist specifically to serve embedding search at scale. I did not choose Postgres by default; the architecture decision record for this stack lays out two independent reasons, and both still hold:

1. The corpus size makes a dedicated vector database unnecessary. The confirmed scope for this app is 50 to 200 uploaded documents — real retrieval-augmented generation over a curated matter file, not context-stuffing an entire jurisdiction's case law. At a few hundred documents, chunked into a few hundred characters each, the chunks table holds a few tens of thousands of rows, not billions. A dedicated ANN (approximate nearest neighbor) index earns its keep once a corpus reaches the high hundreds of thousands or millions of vectors; below that, an exact nearest-neighbor scan over an ordinary table is fast enough that the extra moving part is not worth the operational cost of running, syncing, and paying for a second database.

2. Everything else in this app already lives in Postgres. Chunk.embedding is one column on an ordinary SQLAlchemy-mapped table, sitting right next to Chunk.document_id, Chunk.page_number, and Chunk.text. The retrieval query in app/rag/retrieval.py is a single SQL statement that joins chunks to documents and orders by cosine distance in the same breath — no separate round trip to a vector service, no keeping two databases' data in sync, no risk of a Document row and its embeddings drifting out of step because one system committed and the other did not. Postgres's transactional guarantees cover the vectors exactly the same way they cover everything else.

There is a genuine tradeoff being accepted here, and it is worth naming rather than glossing over: pgvector supports both exact and approximate search (it ships ivfflat and hnsw index types for the latter), but as of this post, nsw-legal-research-assistant does not create either kind of index on chunks.embedding — every retrieval query in retrieval.py is a full, exact scan ordered by the <=> cosine-distance operator. That is a deliberate v0 choice, not an oversight: an exact scan over tens of thousands of rows on a laptop returns in well under the time a network round trip to an external LLM provider takes anyway, so an index would be optimizing a part of the request that is not the bottleneck. It is also exactly the kind of decision that needs revisiting, not repeating from memory, once the corpus grows past this app's current scale — and the fact that it is a one-line CREATE INDEX away, on the same table, in the same database, rather than a migration to a different system, is itself part of the case for Postgres.

The schema

Nine tables, all defined in one file (backend/app/models.py), UUID primary keys throughout:

The relationships that matter for retrieval — everything else either hangs off Document or stands alone:

Every one of the 20,354 real rows Part 7 queries lives in the CHUNK box, and every one of them traces back through exactly one DOCUMENT to exactly one COLLECTION — which is the entire mechanism behind scoping a question to "just the Lemon Law collection" rather than searching the whole 146-document corpus.

The table that matters most for this post is Chunk:

class Chunk(Base): is a Python class — a blueprint for creating objects that bundle data together (Part 6 explains classes, objects, and inheritance from first principles if this is unfamiliar). Chunk inheriting from Base is what tells SQLAlchemy "this class corresponds to a real database table," and every line inside it declares one column: id: Mapped[uuid.UUID] = mapped_column(...) reads as "this class has an attribute called id, typed as a UUID (Mapped[uuid.UUID] is a type hint, also covered in Part 6), backed by a real Postgres column configured by mapped_column(...)." This is an ORM (Object-Relational Mapper) — the whole point of it is that Python code elsewhere in the app can write chunk.page_number or chunk.embedding as ordinary attribute access, and SQLAlchemy translates that, behind the scenes, into the real SQL SELECT/INSERT/UPDATE statements Postgres actually understands, without this app's own code ever writing raw SQL by hand for the common cases. Vector(EMBEDDING_DIM) comes from the pgvector.sqlalchemy package — a thin SQLAlchemy type that maps a Python list[float] straight onto Postgres's vector column type, with no manual serialization on either side. EMBEDDING_DIM is fixed at table-creation time and has to match whichever embedding model actually wrote the vectors — 768 dimensions for the default nomic-embed-text (served locally through Ollama), 1536 for OpenAI's text-embedding-3-small if the provider is switched. Part 2 covers why that switch is a column migration, not a config flip; it has not changed here.

Retrieval reads that column with pgvector's cosine_distance() helper, joined directly against Document in one query:

That compiles to ordinary SQL using pgvector's <=> operator (cosine distance; 1 - distance gives cosine similarity) — the same operator I use directly from psql later in this post to sanity-check the database independently of the application code sitting on top of it.

Standing up the Postgres server, step by step

This is the part written for whoever has to actually provision this — not necessarily me, not necessarily someone who has read the application code above. Everything here assumes Docker as the host and works from a base Postgres image up, exactly as the real docker-compose.yml in the repo does.

1. Decide how the vector extension gets into the image

Postgres does not ship the pgvector extension by default — CREATE EXTENSION vector fails on a stock postgres image because the extension's compiled binary is not present on disk. There are two legitimate ways to get it there, and it is worth understanding both even though the app itself only uses the first:

Option A — pull the prebuilt image. The pgvector project publishes ready-made images on Docker Hub that are a stock Postgres image with the extension already compiled in:

This is what nsw-legal-research-assistant actually uses. pg16 is one of several supported tags (pg13 through pg18, each also available pinned to a Debian codename like pg16-bookworm), so the tag chooses the Postgres major version, not a separate pgvector version.

Option B — build it yourself from a base Postgres image. If a hardened or centrally-approved base image is a requirement (common in a regulated environment where "pull a community image from Docker Hub" is not an acceptable answer to "where did this container come from"), the pgvector maintainers' own Dockerfile shows exactly what Option A does under the hood, starting from the official postgres image:

Worth reading line by line rather than skimming: it installs the build toolchain (build-essential, postgresql-server-dev-16 for the matching server headers), compiles pgvector from a pinned tag (v0.8.6, not a floating branch), installs it, then removes the build toolchain again in the same layer so the final image does not carry a C compiler it no longer needs. That last step is not cosmetic — it is the difference between a production image and a development one sitting in the same registry.

2. Write the Compose service

The real service definition, unmodified, from docker-compose.yml:

Four things a system administrator reading this for the first time should not skip past:

- pg_data is a named volume, not a bind mount. Postgres's on-disk files live inside a volume Docker manages, so the data survives docker compose down and container recreation — it is only lost if the volume itself is explicitly removed (docker compose down -v).

- The healthcheck runs pg_isready, not a raw TCP check. A container can accept TCP connections before Postgres has finished its startup recovery; pg_isready asks the server itself whether it is ready to accept queries, which is what the backend service's depends_on: postgres: condition: service_healthy actually waits on before starting.

- POSTGRES_PASSWORD defaults to changeme. That default exists so docker compose up works with zero configuration for local development — it is not a production credential, and anything beyond a laptop needs a real value supplied via .env, never the default left in place.

- Docker Compose derives the project name — and therefore volume names — from the directory name by default. Two independent checkouts of the same repo on one machine, both named nsw-legal-research-assistant, will silently share the same pg_data volume: a real gotcha the build log for this app records hitting during a clean-checkout test. Set COMPOSE_PROJECT_NAME explicitly if more than one instance ever needs to coexist on the same host.

3. Enable the extension via an init script, not a manual step

Pulling an image with pgvector's binary compiled in is not the same as the extension being active in a given database — CREATE EXTENSION still has to run once, per database. Rather than remembering to run that by hand after every fresh volume, the official Postgres image runs any .sql file it finds under /docker-entrypoint-initdb.d/ automatically, exactly once, the first time it starts against an empty data directory. The real init script is one line:

...mounted straight into that directory in the Compose file above (./backend/db/init:/docker-entrypoint-initdb.d). Numbering the file 001_ costs nothing now and matters the moment a second init script is ever added, since the entrypoint runs everything in that directory in filename order.

4. Bring it up and verify independently of the application

Then check the extension actually activated, without going anywhere near the FastAPI backend:

5. Let the application create its own schema — and know the one real gotcha in doing so

nsw-legal-research-assistant does not use a migration framework. Tables are created directly from the SQLAlchemy models on backend startup:

That is a reasonable v0 choice, and it comes with exactly one sharp edge worth knowing before it bites: create_all() only creates tables that do not exist yet. It will never add a column to a table that is already there. This app hit that directly when Brief.llm_provider was added to the model after real matter data already existed in a running briefs table — the fix was one manual, additive statement run directly against the database:

Nullable, no default-value backfill needed, so the statement was safe to run against a live table. That will not always be true for every future column — worth remembering before treating create_all()-only as free forever.

6. Run a retrieval query by hand

Useful for confirming the database layer works entirely independently of the Python application sitting on top of it — pass a query vector directly and let Postgres do the ranking:

<=> is pgvector's cosine-distance operator; 1 - distance gives the same cosine-similarity number retrieval.py computes in Python. In production this vector comes from actually embedding a question through whichever provider ingested the corpus — nomic-embed-text by default — but for a sanity check, any 768-dimension vector confirms the operator, the index-free scan, and the column type all work together end to end, without the LLM orchestration layer in the way.

The same result, scaffolded with Claude Code and Spec Kit

Everything above is how this database layer actually came to exist — written by hand, one file at a time, validated against a live stack at each phase. There is a second, increasingly common way a Claude Code user could arrive at the identical result: Spec Kit, GitHub's open-source toolkit for spec-driven development. I have not run Spec Kit against this app — what follows is a grounded description of the real workflow, not a transcript of a session that happened.

Spec Kit is worth pointing out here specifically because agentic-ai-for-professionals already practises a hand-rolled version of the same discipline: every architectural decision behind this database layer — Postgres over a dedicated vector store, the two-stage retrieval design, the trust-tier columns — lives in a numbered ADR under llmwiki/wiki/architecture/, written before or alongside the code, not reverse-engineered from it afterward. Spec Kit formalizes exactly that habit — specify before plan, plan before tasks, tasks before implementation — as a set of slash commands with real, versioned artifacts on disk, rather than a wiki convention a team has to remember to follow.

Install and initialize. Spec Kit ships as a CLI, specify, installed via uv:

For an existing project — adding this database layer to an already-running app tree, rather than starting a repo from nothing — initialize in place:

--integration claude installs Spec Kit's skills into .claude/skills, which is how Claude Code discovers the /speckit-* commands below. --here targets the current directory instead of scaffolding a new one; --force allows that in a directory that already has files in it, which this one does.

Run the workflow. Constitution is set once per project; specify through converge repeat per feature — here, one feature: the database layer itself.

Each command hands off a real artifact to the next rather than passing instructions along conversationally: /speckit-specify writes spec.md, /speckit-plan writes plan.md capturing exactly the technology decisions given above, /speckit-tasks turns that plan into a dependency-ordered tasks.md — something in the shape of "create the Compose service and init script" before "define the SQLAlchemy models" before "wire the cosine-distance retrieval query," each task explicit about what it depends on finishing first. /speckit-implement works through that list; /speckit-converge checks the result against spec.md and reports whether it actually satisfies what was asked for, repeating with /speckit-implement until it does. All of it lands under .specify/ in the repo, reviewable the same way the hand-written ADRs above are — the difference is that Spec Kit enforces the specify-before-plan-before-tasks ordering structurally, where this repo's own wiki convention only enforces it by habit.

Where this genuinely earns its keep over building by hand is exactly the gotcha from step 5 above: adding Brief.llm_provider to a live table. Run through /speckit-specify ("add a per-brief LLM provider override, nullable, no backfill needed") and /speckit-plan ("this is an additive column on an existing table with real data — no migration framework in place, so the plan has to state the manual ALTER TABLE explicitly and confirm nullability makes it safe"), that decision and its reasoning end up written down in plan.md before the ALTER TABLE statement runs, rather than living only in a README paragraph written after the fact — which is, not coincidentally, exactly the same distinction between "decided and recorded" and "decided and remembered" that this repo's own ADR practice exists to close.

Check your understanding

1. In the toy cosine distance example, "about cats" ([0.9, 0.1, 0]) scored 0.0061 against the query [1, 0, 0]. Without running any SQL, would you expect a fourth toy row, [0.5, 0.5, 0], to score closer to 0 or closer to 1? Why?

2. chunks.embedding is declared vector(768), fixed at table-creation time. If the app switched its embedding model from nomic-embed-text (768 dimensions) to OpenAI's text-embedding-3-small (1536 dimensions) tomorrow, would ALTER TABLE chunks ALTER COLUMN embedding TYPE vector(1536); alone be enough to make retrieval work correctly again? What else would have to happen to the 20,354 rows already in that column?

3. This post says nsw-legal-research-assistant creates no ivfflat or hnsw index on chunks.embedding. If the corpus grew from 146 documents to 146,000, what would you expect to happen to query time, and at what point would adding an index stop being optional?

4. Base.metadata.create_all(bind=engine) runs on every backend startup. If you deleted the Chunk class from models.py entirely and restarted the backend, would the real chunks table in Postgres — and its 20,354 rows — be dropped? Why or why not?
