TEXT

1ALProjectQRCodeGenerator/
2├── .vscode/
3├── .alpackages/
4├── .git/
5├── .snapshots/
6├── app.json
7├── Customer Card QR Extension.al
8├── Customer QR Code FactBox.al
9├── QR Code Helper.al
10├── QR Code Media.al
11└── Neil Haddley_ALProjectQRCodeGenerator_1.0.0.0.app

CODE

1Customer Card → FactBox → Helper → Azure Function → MediaSet Storage → Display

AL

1table 50100 "QR Code Media"
2{
3    fields
4    {
5        "Customer No." (Code[20])      // Primary key, links to Customer
6        "Media ID" (Media)             // Legacy binary storage field
7        "QR Code Image" (MediaSet)     // Active field for UI display
8        "Created DateTime" (DateTime)   // Auto-timestamp on insert
9    }
10
11    trigger OnInsert()
12    {
13        "Created DateTime" := CurrentDateTime;  // Auto-populate timestamp
14    }
15}

CODE

11. Validate customer exists
22. Build QR text content (customer number + name)
33. Construct API URL with encoded parameters
44. Detect response format (base64 vs binary)
55. Call Azure Function via HttpClient
66. Convert response to MediaSet
77. Store in database
88. Return MediaId GUID

AL

1page 50100 "Customer QR Code FactBox"
2{
3    PageType = CardPart;
4    SourceTable = "QR Code Media";
5
6    layout {
7        field("QR Code Image")    // MediaSet displays as image
8        label("Scan to view...")  // User guidance text
9    }
10
11    trigger OnOpenPage() {
12        if Rec.IsEmpty() then
13            GenerateQRCode();  // Auto-generate if missing
14    }
15}

AL

1pageextension 50100 extends "Customer Card"
2{
3    layout {
4        addfirst(factboxes) {
5            part(QRCodeFactBox; "Customer QR Code FactBox") {
6                SubPageLink = "Customer No." = FIELD("No.");
7            }
8        }
9    }
10}

CODE

1User opens Customer "C001"
2  ↓
3FactBox checks QR Code Media for "C001"
4  ↓
5Not found → Calls GenerateQRCodeForCustomer("C001")
6  ↓
7Helper builds: "CUSTOMER:C001|NAME:Contoso Ltd"
8  ↓
9Calls: https://azure-function.../api/QRCodeGenerator?text=CUSTOMER%3AC001...
10  ↓
12  ↓
13Converts base64 → binary stream → MediaSet
14  ↓
15Stores in QR Code Media table
16  ↓
17FactBox displays QR code image
18  ↓
19User scans with phone → Sees customer info

JSON

1{
2  "id": "d3c72ccb-3945-46b3-8e4e-b784aaf1bd69",
3  "name": "ALProjectQRCodeGenerator",
4  "publisher": "Neil Haddley",
5  "version": "1.0.0.0",
6  "brief": "",
7  "description": "",
8  "privacyStatement": "",
9  "EULA": "",
10  "help": "",
11  "url": "",
12  "logo": "",
13  "dependencies": [
14    {
15      "id": "437dbf0e-84ff-417a-965d-ed2bb9650972",
16      "name": "Base Application",
17      "publisher": "Microsoft",
18      "version": "27.0.0.0"
19    },
20    {
21      "id": "63ca2fa4-4f03-4f2b-a480-172fef340d3f",
22      "name": "System Application",
23      "publisher": "Microsoft",
24      "version": "27.0.0.0"
25    }
26  ],
27  "screenshots": [],
28  "platform": "1.0.0.0",
29  "application": "27.0.0.0",
30  "idRanges": [
31    {
32      "from": 50100,
33      "to": 50149
34    }
35  ],
36  "resourceExposurePolicy": {
37    "allowDebugging": true,
38    "allowDownloadingSource": true,
39    "includeSourceInSymbolFile": true
40  },
41  "runtime": "16.0",
42  "features": [
43    "NoImplicitWith"
44  ]
45}

CODE

1pageextension 50100 "Customer Card QR Extension" extends "Customer Card"
2{
3    layout
4    {
5        addfirst(factboxes)
6        {
7            part(QRCodeFactBox; "Customer QR Code FactBox")
8            {
9                ApplicationArea = All;
10                SubPageLink = "Customer No." = FIELD("No.");
11            }
12        }
13    }
14}

CODE

1page 50100 "Customer QR Code FactBox"
2{
3    PageType = CardPart;
4    SourceTable = "QR Code Media";
5    Caption = 'Customer QR Code';
6
7    layout
8    {
9        area(Content)
10        {
11            group(QRCodeGroup)
12            {
13                ShowCaption = false;
14                field(QRCodeImage; Rec."QR Code Image")
15                {
16                    ApplicationArea = All;
17                    ShowCaption = false;
18                    Editable = false;
19                    ToolTip = 'QR Code for customer';
20                }
21                label(Description)
22                {
23                    ApplicationArea = All;
24                    Caption = 'Scan to view customer details';
25                    Style = Subordinate;
26                }
27            }
28        }
29    }
30
31    var
32        QRCodeHelper: Codeunit "QR Code Helper";
33
34    trigger OnAfterGetRecord()
35    begin
36        // Record already loaded
37    end;
38
39    trigger OnOpenPage()
40    begin
41        // Generate QR code if it doesn't exist
42        if Rec.IsEmpty() then
43            GenerateQRCode();
44    end;
45
46    local procedure GenerateQRCode()
47    var
48        Customer: Record Customer;
49    begin
50        if Customer.Get(Rec."Customer No.") then
51            QRCodeHelper.GenerateQRCodeForCustomer(Customer."No.");
52
53        // Refresh the page to show the new QR code
54        if Rec.Get(Rec."Customer No.") then;
55    end;
56}

CODE

1codeunit 50100 "QR Code Helper"
2{
3    // This function generates a QR code for a customer and stores it
4    procedure GenerateQRCodeForCustomer(CustomerNo: Code[20]): Guid
5    var
6        Customer: Record Customer;
7        HttpClient: HttpClient;
8        HttpResponse: HttpResponseMessage;
9        ResponseText: Text;
10        InStr: InStream;
11        FunctionUrl: Text;
12        QRCodeText: Text;
13        ImageMediaId: Guid;
14        UseBase64: Boolean;
15    begin
16        // 1. Get the customer record
17        if not Customer.Get(CustomerNo) then
18            exit;
19
20        // 2. Build the text to encode in the QR code
21        QRCodeText := GetCustomerQRText(Customer);
22
23        // 3. Build the full URL with encoded query parameter
24        FunctionUrl := GetFunctionUrl() + EncodeUrl(QRCodeText);
25        UseBase64 := IsBase64Response(FunctionUrl);
26
27        // 4. Call the API to generate QR code
28        if not HttpClient.Get(FunctionUrl, HttpResponse) then
29            Error('Failed to call QR code generation service');
30
31        if not HttpResponse.IsSuccessStatusCode() then
32            Error('Failed to generate QR code. Status: %1', HttpResponse.HttpStatusCode());
33
34        // 5. Get the response content
35        if UseBase64 then begin
36            if not HttpResponse.Content.ReadAs(ResponseText) then
37                Error('Failed to read response content');
38            ImageMediaId := StoreQRCodeImageFromBase64(CustomerNo, ResponseText);
39        end else begin
40            if not HttpResponse.Content.ReadAs(InStr) then
41                Error('Failed to read response content');
42            ImageMediaId := StoreQRCodeImage(CustomerNo, InStr);
43        end;
44
45        exit(ImageMediaId);
46    end;
47
48    local procedure EncodeUrl(TextToEncode: Text): Text
49    var
50        TypeHelper: Codeunit "Type Helper";
51    begin
52        exit(TypeHelper.UriEscapeDataString(TextToEncode));
53    end;
54
55    local procedure GetCustomerQRText(Customer: Record Customer): Text
56    var
57        CompanyInfo: Record "Company Information";
58        BaseUrl: Text;
59    begin
60        // Customize this based on what you want in the QR code
61        if CompanyInfo.Get() then
62            BaseUrl := CompanyInfo."Home Page"; // Or your Business Central base URL
63
64        // Example 1: URL to the customer card in Business Central
65        // exit(StrSubstNo('%1?page=21&bookmark=Customer.''No.''=%2', BaseUrl, Customer."No."));
66
67        // Example 2: Simple customer information
68        exit(StrSubstNo('CUSTOMER:%1|NAME:%2', Customer."No.", Customer.Name));
69    end;
70
71    local procedure StoreQRCodeImageFromBase64(CustomerNo: Code[20]; Base64DataUri: Text): Guid
72    var
73        QRCodeMedia: Record "QR Code Media";
74        Base64Convert: Codeunit "Base64 Convert";
75        TempBlob: Codeunit "Temp Blob";
76        InStr: InStream;
77        OutStr: OutStream;
78        Base64Data: Text;
79        PrefixPos: Integer;
80    begin
81        // Check if record already exists
82        if QRCodeMedia.Get(CustomerNo) then
83            QRCodeMedia.Delete();
84
85        // Extract base64 data from data URI
87        PrefixPos := StrPos(Base64DataUri, ',');
88        if PrefixPos > 0 then
89            Base64Data := CopyStr(Base64DataUri, PrefixPos + 1)
90        else
91            Base64Data := Base64DataUri;
92
93        // Convert base64 to stream
94        TempBlob.CreateOutStream(OutStr);
95        Base64Convert.FromBase64(Base64Data, OutStr);
96        TempBlob.CreateInStream(InStr);
97
98        // Create a new record
99        QRCodeMedia.Init();
100        QRCodeMedia."Customer No." := CustomerNo;
101
102        // Import into MediaSet field
103        QRCodeMedia."QR Code Image".ImportStream(InStr, 'QRCode.png');
104        QRCodeMedia.Insert(true);
105
106        exit(QRCodeMedia."QR Code Image".MediaId());
107    end;
108
109    local procedure StoreQRCodeImage(CustomerNo: Code[20]; InStr: InStream): Guid
110    var
111        QRCodeMedia: Record "QR Code Media";
112    begin
113        // Check if record already exists
114        if QRCodeMedia.Get(CustomerNo) then
115            QRCodeMedia.Delete();
116
117        // Create a new record in our custom media table
118        QRCodeMedia.Init();
119        QRCodeMedia."Customer No." := CustomerNo;
120        QRCodeMedia."QR Code Image".ImportStream(InStr, 'QRCode.png');
121        QRCodeMedia.Insert(true);
122
123        exit(QRCodeMedia."QR Code Image".MediaId());
124    end;
125
126    local procedure GetFunctionUrl(): Text
127    begin
128
129        // Your Azure Function that returns base64 data URI
130        exit('https://qrcode-generator-function-e5c2d8dwcabsbbfe.eastus-01.azurewebsites.net/api/QRCodeGenerator?text=');
131
132
133        // Alternative: Using public QR API (returns binary PNG directly)
134        //exit('https://api.qrserver.com/v1/create-qr-code/?size=200x200&data=');
135    end;
136
137    local procedure IsBase64Response(Url: Text): Boolean
138    begin
139        // Returns true if the configured API returns base64 data URI
140        // Azure Functions typically return base64, public APIs return binary
141        exit(StrPos(Url, 'azurewebsites') > 0);
142    end;
143
144    local procedure GetFunctionKey(): Text
145    begin
146        // IMPORTANT: Use Isolated Storage or Azure Key Vault integration in production
147        exit('your-actual-function-key-here');
148    end;
149}

CODE

1table 50100 "QR Code Media"
2{
3    DataClassification = ToBeClassified;
4
5    fields
6    {
7        field(1; "Customer No."; Code[20])
8        {
9            TableRelation = Customer;
10        }
11        field(2; "Media ID"; Media)
12        {
13            // This field stores the actual image
14            Caption = 'QR Code Image';
15        }
16        field(3; "QR Code Image"; MediaSet)
17        {
18            Caption = 'QR Code';
19        }
20        field(4; "Created DateTime"; DateTime)
21        {
22            Editable = false;
23        }
24    }
25
26    keys
27    {
28        key(PK; "Customer No.")
29        {
30            Clustered = true;
31        }
32    }
33
34    trigger OnInsert()
35    begin
36        "Created DateTime" := CurrentDateTime;
37    end;
38}
